Capacity 10 x GN 1/1 or 10 x 600 x 400 mm
Stainless steel inside and out, rounded inside corners
Insulation 60 mm thick with high-pressure sprayed polyurethane
without CFC or HCFC, digital temperature indicators and
Control with PTC temperature sensor and core temperature sensor
Fully automatic defrosting and condensate evaporation, refrigerant R452a
Rapid cooling capacity: +90 °C / +3 °C - 20 kg
Rapid freezing capacity: +90 °C / -18 °C - 13 kg
Power: 2.2 kW / 400 V
Dimensions: 820 x 860 x 1470 mm
The ECO series of shock freezers is a classic line of shock freezers that combines reliability, robustness and design.
The exterior and interior structure is made of stainless steel. The doors feature automatic closing and a fixed opening position of 100°. The magnetic seal is easily removable. Rounded edges ensure easy and optimal cleaning. The 60 mm thick polyurethane insulation is injected under high pressure and is free of CFCs and HCFCs. Automatic or manual defrosting is possible, with a condensate collection tray. Height-adjustable stainless steel feet are included (except for model SCH-030). Wheels are available upon request. A reversible door is available (except for model SCH-030). The power cord comes standard with a plug.
Rapid cooling or deep freezing is possible for a set time or until the desired temperature is reached. Thanks to the cell's opening fan support, the evaporator is easily accessible for optimal cleaning. The ECO shock freezers are programmable in their cooling cycles to meet a wide range of customer requirements.
STANDARD EQUIPMENT for all models:
* Chamber probe * Core temperature probe * Grate support (1 stainless steel grate)
