The ERGO is powered by a 24V
DC geared motor with energy-efficient
Permanent magnet system. The power transmission
is carried out via a chain transmission.
Easy to push, even without switched on
Engine, is driven by the disengageable wheels
enabled.
The speed is continuously adjustable
is always kept constant by a control system
maintained, even on rough terrain and slight inclines of up to 10%.
The track width is manufactured according to customer specifications.
Technical data
-
watt 140W
-
Motor 24V
-
Battery type Lead
-
Battery system Removable battery
-
charger As an accessory
-
Load capacity 200kg
-
differential gear No
-
Drive tires 4.00.8
-
Battery life 6-8 hours
-
jobs 1 movable
-
Electric brake No
-
speed 0-5 km/h
-
Max. gradient 20%
