Key features
Maximum flow rate 1666 l/min (100 m³/h)
Max. suction height 8 m
Max. total delivery head 30 m
Solids Ø 25 mm
S/D connector 4'' / 4''
Silicone carbide axle seal
Weight approx. [kg] 48
Dimensions L x W x H [mm] 640 × 480 × 540
Motor
Engine type ENDRESS E390
Design: 1-cylinder, 4-stroke, OHV
Engine displacement [cm³] 389
Power at 3600 rpm [kW] 7.6
Fuel: Petrol
Tank capacity [l] 6.5
Runtime at 75% load* 2.1
Starting system: Reverse start
Sound power level LWA [dB(A)] 109
Sound pressure level LPA (7 m) [dB(A)] 87
Features
High delivery rate
High-quality seals
Low oil shutdown system
3 x hose clamps
2 x hose couplings
1 x suction basket
1 x spark plug wrench
2 x Seal for hose coupling
2x hose connection
Technical specifications and illustrations are non-binding.
