Key features
Maximum power (LTP) [kVA/kW] 13.67/10.94
Continuous power (PRP) [kVA/kW] 12.81/10.25
Nominal voltage [V] 400/230
Frequency [Hz] 50
Rated current 3~ (PRP) [A] 18.5
Power factor [cos ϕ] 0.8
Sockets: 1x CEE 400V / 32A
1x CEE 400V / 16A
2x CEE 230V / 16A
1x 230V / 16A
Dimensions and weight
Dimensions L x W x H [mm] 1645 x 870 x 1072
Weight approx. [kg] 480
Tank capacity [l] 51
autonomy
Runtime at 75% load [h] 20.2
Sound power
Sound power level LWA [dB(A)] 93
Sound pressure level LPA (7 m) [dB(A)] 68
Motor
Yanmar brand
Model 3TNV88F-UGPGE
Emissions standard Stage V
Number of cylinders, engine arrangement: 3L
Cooling system water-cooled
Engine displacement [cm³] 1642
Engine power (PRP) [kW] 12.4
Engine power (LTP) [kW] 13.2
CO2 emissions [g / kWh] kA (Stage V)
CO2 test procedure kA (Stage V)
Speed [rpm] 1500
Mechanical speed control
Starting system: electric start
On-board voltage [V] 12
Battery capacity [Ah] 70
Fuel: Diesel
Specific fuel consumption at 75% PRP [g/kWh] 227
Oil quantity [l] 6.7
Coolant quantity [l] 2
Starter motor [kW] 1.2
Generator brand MeccAlte ECP3-2L Generator type synchronous Insulation class Class H Voltage regulation electronic Protection class [IP] 23 Number of poles 4 Frequency [Hz] 50 Frequency tolerance [%] ±1 Voltage stability at speed deviation -5% +30% [%] 1 Power factor [cos ϕ] 0.8 Efficiency at 75% load [%] 87.6 Voltage regulator DSR THD Full load LL/LN [%] 2.2 / 2.0 THD No load LL/LN [%] 2.8 / 2.7 THF [%] <2 Short-circuit current [%] >300 Features Engine compliant with emissions standard Stage V Galvanized hood for increased corrosion protection Central crane lifting eye Protection via circuit breaker Soundproof housing for low operating noise
