Key features
Synchronous generator type
Max. output 3~ [kVA/kW] 18.16/14.53
Continuous power output 3~ [kVA/kW] 16.19/12.95
Nominal voltage [V] 400/230
Rated current [A] 24.6
Power factor [cos ϕ] 0.8
Frequency [Hz] 50
Generator protection class [IP] 23
Motor
Engine type Yanmar - 3TNV80-FPGE
Engine displacement [cm³] 1267
Emissions standard Stage V
Fuel: Diesel
Tank capacity [l] 51
Consumption at 75% load [l/h] 4.6
Consumption at 100% load [l/h] 5.99
Runtime at 75% load [h] 11.06
Starting system: electric start
Sound power level LWA [dB(A)] 96
Sound pressure level LPA (7 m) [dB(A)] 71
Weight approx. [kg] 475
Dimensions L x W x H [mm] 1500 x 754 x 1032
Socket 1 x 230 V/16 A
1 x CEE 230 V/16 A
1 x CEE 400 V/16 A
1 x CEE 400 V/32 A
Features
Large tank for long operating times
Fuel level indicator
3-phase voltage regulator AVR
Low oil shutdown system
Soundproof housing for low operating noise
Central crane loading eye
Manual/Automatic Control Panel
Remote start device
Including insulation monitoring according to VDE 0100-551 2017.02
