Key features
Maximum power (LTP) [kVA/kW] 19.34/15.47
Continuous power (PRP) [kVA/kW] 18.35/14.68
Nominal voltage [V] 400/230
Frequency [Hz] 50
Rated current 3~ (PRP) [A] 26.5
Power factor [cos ϕ] 0.8
Sockets: 1x CEE 400V / 32A
1x CEE 400V / 16A
2x CEE 230V / 16A
1x 230V / 16A
Dimensions and weight
Dimensions L x W x H [mm] 1645 x 870 x 1072
Weight approx. [kg] 495
Tank capacity [l] 51
autonomy
Runtime at 75% load [h] 13.8
Sound power
Sound power level LWA [dB(A)] 93
Sound pressure level LPA (7 m) [dB(A)] 68
Motor
YANMAR brand
Model 4TNV88-BIPGE
Emissions standard Stage V
Number of cylinders, engine arrangement: 4L
Cooling system water-cooled
Engine displacement [cm³] 2190
Engine power (PRP) [kW] 16.8
CO2 emissions [g / kWh] kA (Stage V)
CO2 test procedure kA (Stage V)
Speed [rpm] 1500
Mechanical speed control
Starting system: electric start
On-board voltage [V] 12
Battery capacity [Ah] 80
Fuel: Diesel
Specific fuel consumption at 75% PRP [g/kWh] 240
Oil quantity [l] 7.4
Coolant quantity [l] 2.7
Fuel consumption at 75% load PRP [l/h] 3.69
Generator Brand Mecc Alte ECP28-M4 C Generator Type ECP28-M4 C Insulation Class Class H Voltage Regulation Electronic Protection Class [IP] 23 Number of Poles 4 Frequency [Hz] 60 Frequency Tolerance [%] ±1 Voltage Stability at Speed Variation -5% +30% [%] 1 Power Factor [cos ϕ] 0.8 Efficiency at 75% Load [%] 89.1 Voltage Regulator DSR THD Full Load LL/LN [%] 2.0 / 2.0 THD No Load LL/LN [%] 3.6 / 3.5 THF [%] <2 Short-Circuit Current [%] >300 Features Engine compliant with emissions standard Stage V Galvanized hood for increased corrosion protection Central crane lifting eye Protection via circuit breaker Soundproof housing for low operating noise
