Key features
Synchronous generator type
Max. output 1~ [kVA/kW] 5.9/5.3
Continuous power output 1~ [kVA/kW] 4.8/4.3
Nominal voltage [V] 230
Rated current [A] 21.3
Power factor [cos ϕ] 0.9
Frequency [Hz] 50
Generator protection class [IP] 23
Motor
Engine type YANMAR L 100 / 10 HP
Design: 1-cylinder, 4-stroke
Engine displacement [cm³] 435
Power output at 3000 rpm: 5.7
CO2 emissions [g / kWh] kA (Stage III)
CO2 test procedure kA (Stage III)
Fuel: Diesel
Tank capacity [l] 24
Runtime at 75% load [h] 16
Starting system: Reverse start
Sound power level LWA [dB(A)] 93
Weight approx. [kg] 186
Dimensions L x W x H [mm] 945 x 595 x 825
Socket 1 x 230 V/16 A
1 x CEE 230 V/16 A
1 x CEE 230 V/32 A
Features
Soundproof housing for low operating noise
Large tank for long operating times
Generator overload protection
Residual current circuit breaker (RCCB)
Voltmeter
crane loading eye
12V starter battery
Remote start connection
