- Insert height in mm: 330
- single-walled
- double-walled door
- atmospheric boiler, replaceable polypropylene flush arms/nozzles
- CNS inner tub / wash tank, rounded corners
- electronic control
- Digital display, control system, connection box centrally located on the rear of the device, connection cable
- automatic self-cleaning program, soft start program to protect sensitive materials (glass, porcelain, etc.)
- PVC water supply, cold / hot water connection
- Service / maintenance components accessible from the front
Article number: 406400237
GTIN: 4063377152822
Washing programs (number | duration in seconds): 2 | 120 / 180
Exterior cladding: CNS 1.4301, rear wall made of galvanized sheet steel
Interior paneling: CNS 1.4301
Detergent dosage: Series
Rinse aid dosage: Series
Water softener: series
Fault diagnosis system: Series
Self-cleaning system: Series
Pressure booster pump: Series
Drain pump: Series
Boiler capacity: 5.80 l
Tank capacity: 33.00 l
Theoretical capacity baskets/h: 30
Theoretical performance plate/h: 540
Rinse cycle: 80 to 90 °C
Water inlet: up to max. 50 °C
Gross weight: 64 kg
Net weight: 54 kg
Flushing temperature range: 55 to 65 °C
Production step: Cleaning
Outside width: 600
External depth: 648
External height: 840
Width inside: 500
Depth inside: 500
Height inside: 330
Depth with flap open: 980
Packaging width: 590
Depth of packaging: 690
Packaging height: 920
Energy type: Electric
Electrical connection value: 5.40 kW | 400 V | 3N | 50 Hz
Boiler heating connection value: 4.50 kW
Water hardness: from 5 °dH
Water pressure: 0.5 to 7 bar
Water consumption / cycle: 3.00 l
Protection class: IPX4 - splash-proof
Noise level: approx. 70 dB
Control: electronic control
