- Material: (Housing) Stainless steel AISI 304
- Pool with cold zone
- Includes 1 basket per basin
- With drain tap for easy oil change
- Stepless temperature setting from 90 °C to 190 °C
- Safety thermostat
- Tiltable heating elements for easy cleaning
- Connectable design (bridges available as an option)
- Dimensions: W 600 x D 600 x H 270 / 460 mm (incl. chimney)
- Basket: 2 x W 225 x D280 x H 115 mm
- Contents: 10 + 10 liters
- Connection: 400 V - 50 - 60 Hz - 18 kW
- Weight (net/gross): 41 / 45 kg
- On-site service
____________________________
Safety and warning instructions
- Installation should only be carried out by qualified professional installers.
- Dispose of packaging materials safely to avoid the risk of suffocation.
- Clean the device thoroughly and check for visible damage before first use. Do not use if damaged.
- Ensure that the device is placed on a stable, level and heat-resistant surface.
- Surfaces can become very hot during operation; risk of burns! Avoid contact.
- Always keep the oil level between the minimum (MIN) and maximum (MAX) marks. Never fill below or above these limits.
- Clean only with a soft cloth and mild detergent; do not use abrasive or acidic agents.
- Use the drain tap regularly to change the oil safely and hygienically.
Never extinguish grease fires with water; use a suitable fire extinguisher.
Never clean the device with a water jet or pressure washer.
- Regularly clean basins with cold zones to remove residues and extend the oil's lifespan.
- Allow the device to cool down completely and disconnect it from the mains power supply after each use before cleaning.
- Keep children and unauthorized persons away from the device to avoid misuse and injury.
- In case of visible damage or malfunctions, stop operation immediately and contact specialist personnel.
