Electric double continuous furnaces incl. base frame / tunnel furnace / PO/KD 70 E
With its high heat output, this gas stove offers ideal conditions for stir-fries or large quantities. Order now in our online shop – a German-made catering solution for your business.
User experience
- "Shorter cooking times allow for mass production"
- in busy commercial kitchens."
- Shorter ramp-up times
- Shorter cooking times
- Uniform cooking experience
- Elimination of the need for expensive ventilation systems
- Easy cleaning thanks to the removable strap and parts.
- Key features
- Temperature control from 150 degrees to 350 degrees
- Adjustable belt and cooking speed.
- Cooking chamber made of galvanized steel
- Stackable up to 3 ovens
- Available in gas and electric versions
- Cooking times are adjustable between 1 min and 30 min.
- All 4 sides of the oven are insulated.
- Microprocessor-enabled belt drive
- Robust base frame with swivel casters
- Silent operation with a noise level below 65 dBA.
- User-friendly electronic membrane panel
Technical specifications – PO-KD series electric continuous oven (Double)
The PO-KD series double-deck electric continuous furnaces are ideal for businesses with high throughput.
Production volume. Thanks to its larger baking surface, two levels, and powerful electric motor.
These heating systems offer maximum efficiency and consistent baking quality. Below you will find the...
Technical specifications of the models PO-KD-50-E, PO-KD-70-E and PO-KD-85-E.
| Model "Double" |
PO-KD-50-E
|
PO-KD-70-E
|
PO-KD-85-E
|
| Baking area (m²) |
1.24 m² |
1.40 m² |
1.70 m² |
| Number of floors |
2 |
2 |
2 |
| Conveyor belt dimensions (mm) |
500 × 1425 mm |
700 × 1670 mm |
850 × 1820 mm |
| Width – A (mm) |
1520 mm |
1400 mm |
1900 mm |
| Depth – B (mm) |
1050 mm |
1270 mm |
1400 mm |
| Height – C (mm) |
920 mm |
1140 mm |
1280 mm |
| Work surface dimensions (mm) |
500 mm |
500 mm |
500 mm |
| Electrical power |
20 kW 400V 50–60 Hz 3F+N |
30 kW 400V 50–60 Hz 3F+N |
44 kW 400V 50–60 Hz 3F+N |
| Thermal output |
8–10 kW/h |
16–20 kW/h |
24–26 kW/h |
| Maximum temperature |
350 °C |
350 °C |
350 °C |
| Weight of the oven |
320 kg |
430 kg |
610 kg |
| Pallet dimensions (mm) |
1080×1440×11000 mm |
1250×1700×14600 mm |
1350×1850×15000 mm |
| Control system |
Digital |
Digital |
Digital |
| Energy source |
Electrically |
Electrically |
Electrically |
Additional Information
- It is produced in accordance with hygiene and safety guidelines.
- The devices have the CE marking in accordance with the relevant directives.
- All materials are manufactured according to European food standards.
